Product Description
TONGKUAI large height escalator is effective, energy-saving, highly intellectual and automatic with ow trouble rate, low maintenance rat large lighting height large passenger flow, high performance
TRUMPF always settles down perfect quality into every detail. It owns perfect and leading elevator manufacture technology, constantly superior services. It applies new trouble display system in control sector, It can quickly and accurately diagnoses and removes escalator troubles. Regarding structure, it introduces advanced large-size computer software. It adopts different structural configuration upon different heights of escalator. Under the conditions of ensuring safety, it can greatly enhance utilization rate of materials. Through enlarging up / down curve radius R value, unloading guide rail educes wheel pressure load. It increases comfortable travel and stable escalator operation, prolongs service life of escalator
TONGKUAI large height escalator integrates attraction, safety, environment-protection into one according to harmonious transport concept. It satisfies large passenger flow in subway, railway station, airport, large shopping center etc. It is your trustworthy solution plan.
| Model | TK 30-800（6750people/hour ） | TK 30-1000（9000people/hour ） | Transport size | |||||||||
| Traveling height (mm) | Net height(KN) | Supporting load(KN) | Motor power(KW) | Net height(KN) | Supporting load | Motor power(KW) | h | l | ||||
| R1 | R2 | R3 | R1 | R2 | R3 | |||||||
| 6000 | 107 | 45 | 37 | 93 | 11 | 75 | 51 | 43 | 107 | 15 | 2830 | 17170 |
| 6500 | 111 | 47 | 39 | 98 | 11 | 93 | 53 | 45 | 113 | 15 | 2840 | 18160 |
| 7000 | 116 | 49 | 41 | 103 | 11 | 87 | 56 | 48 | 119 | 15 | 2860 | 19160 |
| 7500 | 120 | 51 | 43 | 108 | 15 | 92 | 58 | 50 | 124 | 15 | 2870 | 20150 |
| 8000 | 125 | 53 | 45 | 113 | 15 | 97 | 60 | 52 | 130 | 18.5 | 2880 | 21140 |
| 8500 | 129 | 55 | 47 | 118 | 15 | 103 | 62 | 54 | 135 | 18.5 | 2890 | 22130 |
| 9000 | 134 | 57 | 49 | 123 | 15 | 110 | 69 | 58 | 144 | 11*2 | 3050 | 23500 |
| 9500 | 139 | 59 | 51 | 128 | 15 | 116 | 71 | 60 | 149 | 11*2 | 3060 | 24490 |
| 10000 | 143 | 61 | 53 | 133 | 18.5 | 122 | 73 | 62 | 154 | 11*2 | 3070 | 25480 |
Q1: Payment Term?
A:T/T or L/C at sight
Q2.What is the warranty period?
A: 12 months after shipment
Q3: What is covered by warranty?
A: Within warrant period, replacement to any broken and defected parts will be provided. Parts in weight of less than 2KG will be delivered by DHL/UPS, while other parts will be delivered by SEA.
Q4. Installation & Maintaining & Technical Support.
A:The complete documents including Installation manual will be delivered along with the elevator in the container .Remote technical support is available via email, what`s app, skype and etc.
If necessary , a technician will be sent to assist you on the worksite upon your request.
Q5: How could I trust you?
A:We have exported to many countries, such as Mid East, Africa, Domestic Market, Southeast Asia, Eastern Europe ,etc.
Q6:Could you accept trade assurance order?
A:Yes, we welcome any trade assurance order, and we have done more than 30 transactions in the past year.
